RC10 4WD 1/10th Electric Kit

RC10 4WD 1/10th Electric Kit

by Team Associated – AS6040
Save 7%
£474.99
£444.00

The RC10 started as the vision of Team Associated’s founder Roger Curtis (RC) and became one of the most iconic RC cars in history.

At the inaugural IFMAR Off Road World Championships, Jay Halsey took first place with his RC10 in the 2WD class, but did you know he also raced a prototype 4WD RC10 in the 4WD class and took second place?

Team Associated never advanced that prototype 4WD and instead focused on 2WD. But what if Team Associated had developed a 4WD RC10? You’d get the RC10 4WD off road buggy!

Our team of engineers took the iconic RC10, the knowledge of 4WD racing from the B74, and created the RC10 4WD. No more having to buy an RC10 kit, a conversion kit, and random parts. Now you can have a genuine Team Associated RC10 4WD that is meant to be raced, with all the parts in one box. All you need to do is add electronics and hit the track!

Front and rear Stealth® transmissions with adjustable ball differentials, race proven V2 slipper clutch system, CVA driveshafts and durable low-friction center belt tension system.

The smooth undercarriage of the RC10’s aluminum monocoque tub and special gearboxes provide maximum ground clearance.

Independent suspension with hard anodized coil-over shocks help smooth out the bumps. Precision molded; nylon suspension components can be easily custom colour dyed. Long front A-Arm/Ball Joint design permits static camber, camber rise, caster, ride height and spring rate tuning to suit every type of track.

Features

  • 4WD gold anodized 6061-T6 aluminum monocoque tub chassis
  • Fully adjustable four-wheel independent suspension
  • Long travel, fluid-filled, hard-anodized aluminum coil-over shocks
  • Race-proven front and rear Stealth® Transmissions
  • Adjustable ball differentials front and rear
  • Exceptional ground clearance with low center of gravity
  • Vintage 4WD spike tires included
  • Clear ProTech body with driver figure and wing
  • New 4WD specific shock towers front and rear
  • Precision bearings throughout
  • Fits 6-cell NiMh and 2S LiPo battery packs
  • Adjustable 3.5mm turnbuckles all around
  • Front and rear CVA driveshafts
  • Durable low-friction center belt and tension system
  • Long front arm geometry
  • All new front caster and spindle assembly designed for RC10 4WD
  • Updated rear bulkhead and chassis stiffener
  • Carbon fiber rear transmission brace
  • Front 2.2” 12mm hex wheels included
  • Rear 2.2” wheels included
  • HD metric ball studs throughout
  • Race-proven V2 slipper clutch system
  • All new 4WD specific bell crank system
  • 5.5” high downforce Lexan® race wing Included

Specifications

Power Source: Electric
Terrain: Off-Road
Body Style: Buggy
Scale Size: 1:10 Scale
Assembly Level: *Kit
Length: 381mm (15in)
Width: 241mm (9.49in)
Wheelbase: 273mm (10.75in)
Weight: Varies
Drive: 4WD

Please Note: *This vehicle comes as a kit and must be fully assembled by the user. See "Needed to Complete" section below for extra items needed..

Needed To Complete

  • 1:10 scale 540-size electric RC car motor
  • 1:10 scale radio control electronic speed control
  • 7.4V-7.6V 2S LiPo with "shorty" battery dimensions (standard or low-profile height)
  • Battery charger (for one of the batteries mentioned above)
  • 2 channel surface transmitter, 2 channel receiver, and steering servo
  • Lexan specific spray paint for body
  • 1:10 scale off-road wheels and tyres
  • 4 x AA batteries for radio-controlled car radio
